Backed by Ryan Villopoto & Carson Brown!!!
Silver = 330-KLX-1135
Black Satin Powder Coat = 330-KLX-1115
Introducing the all new BBR Stock Comp Signature aluminum swingarm for the KLX110!
BBR completely started over in designing this new A-frame style swingarm. The sides are forged from 6061 aluminum for super high strength and increased stiffness. These forgings eliminated the 4 main welds used on our old Super Stock swingarms and allowed for a much more precise fit and finish. The axle dropouts were redesigned to be stronger and allow for more chain adjustment. The shock mount is removable giving you the choice between standard ride height and +1" seat height. All Stock Comp Signature swingarms now include a brake stop for disc brake caliper mounts (fits old BBR disc brake or Diamond Minis KX65 caliper Adapter Kit) or the standard KLX110 brake arm. Finish is bead blasted and then clear anodized. Includes anodized look chrome signature decals from Ryan Villopoto and Carson Brown.
- Forged 6061 aluminum side spars
- TIG welded and heat treated to T6
- Bead blasted and Bright Dip anodized finish
- Ride height adjustable between standard and +1" (both blocks included)
- Uses BBR CRF/XR50 chain guide on all models (included)
- Adds 1.75" over stock length
Includes brake rod extender
I like the look of the updated design but I wish it was still 2.25" or 2.5" extended, whatever it used to be instead of just 1.75. Still looks way better than stock and will hold up better if you're going to be jumping. The chain guide sits a little low for my liking so ill probably take it off.
Bbr swing arm
This is one of the best things I have ever got for my klx110 that ride is great
Overall super easy install and looks really nice until you hit the break arm. Instructions really need a update or Bbr needs to post an installation video on the proper cuts.
You want to leave about 3/4" of threads on the stock rod.
Makes the bike handle so much better! A must when you've given up on big bikes, and are trying to build the next best thing
BBR Rear swing arm
My stock swing arm broke so i ordered the BBR one between the quality and the performance amazing results every bike i get will be getting this swing arm
